MFC 18066

型號:MFC 18066

                     MFC 18066



Size(180mm X 180mm x 66mm)
Motor
Capacitor-Run Induction Motor
Frame
Aluminum Die-Cost
Impeller
PBT + 30% Fiber Glass. UL94V-0
Insulation Resistance

Min 10 M 0hm at 500VDC Between Terminal and the Frame
Dielectric Strength
1 min at 1,500VAC 50/60Hz
Bearing Type
B: 2 Ball Bearing. Operating Temp
Ball Bearing: Within -20 ~ 80°C
Life Expectancy
Ball Bearing: 50,000 hours at 60°C

Net Weight
1450 grams

                                   180 X 180 X 66 mm

PART NO.

Bearing

Rated
Voltage

Freg

Current

input
power

Speed

Max.air
Flow

Max.air
Pressure

Noise

Weight

(V)

(Hz)

(A)

(W)

(R.P.M)

CFM

INH2O

dB-A

grams

18066A1HBAT(L)

Ball

110/120

50/60

0.68/0.57

61/60

2750/3250

380/430

0.72/0.95

61/68

1450

18066A2HBAT(L)

Ball

220/240

50/60

0.23/0.25

50/57

2750/3250

380/430

0.72/0.95

61/68

1450
